The 4 Wheel Drive EV Electric Mini Truck Pickup is an innovative and eco-friendly small electric pickup truck that combines high-performance four-wheel-drive capabilities with pure electric technology, providing users with exceptional performance, reliability, and sustainability. Whether you are an urban resident or a business user, this small electric pickup will meet a variety of your needs.
Powerful Four-Wheel Drive System: Equipped with a robust four-wheel-drive system, it offers excellent traction and maneuverability across various terrains, ensuring you can easily tackle rugged mountain trails or muddy roads.
Zero Emissions: Utilizing pure electric power, it completely eliminates tailpipe emissions, contributing to improved urban air quality and reduced environmental pollution.
Impressive Range: Advanced battery technology ensures a longer range, allowing you to accomplish more tasks without frequent recharging.
Versatile Cargo Bed: The spacious cargo bed of the small electric pickup is suitable for various purposes, such as cargo transport, tool carrying, agricultural applications, and more.
Smart Connectivity: Equipped with advanced smart connectivity technology, you can control the vehicle, check the charging status, and monitor the vehicle’s health through a smartphone app.
Advanced Safety: It includes advanced safety features such as an Anti-lock Braking System, Electronic Stability Control, and multiple airbags to ensure the safety of the driver and passengers.
Cost-Effective: The low maintenance costs, affordable charging expenses, and long-term sustainability make it an economically sound choice for transportation and business purposes.
Comfort: The spacious cabin, user-friendly design, and premium interior provide comfort for both the driver and passengers.
The 4 Wheel Drive EV Electric Mini Truck Pickup is a versatile small electric pickup suitable for urban and rural environments. It offers outstanding performance and a sustainable mobility solution to meet various usage and environmental needs. Whether you require a rugged utility vehicle or seek an eco-friendly mode of transportation, it is your ideal choice.
|
Model ID |
KK1121D10 |
|
Vehicle status |
73.6V 10.5KW |
|
Right hand drive |
○ |
|
Length×Width×Height (mm) |
3650×1510×1820 |
|
Container internal dimensions |
1620X1245X300 |
|
Wheelbase (mm) |
2340 |
|
Front track (mm) |
1315 |
|
Rear track (mm) |
1315 |
|
Front suspension (mm) |
455 |
|
Rear suspention (mm) |
705 |
|
Curb weight (kg) |
880 |
|
Load quality (kg) |
300 |
|
Seats No. |
2 |
|
Gross weight (kg) |
1310 |
|
Performance parameters |
|
|
Max speed (km/h) |
80 |
|
Acceleration time s (0-40km) |
20 |
|
Max grade |
0.35 |
|
Min turning diameter (m) |
≤11 |
|
Maximum angle |
30(outer wheel）/32(inner wheel） |
|
Approach angle (°) |
≥55 |
|
Departure angle (°) |
≥35 |
|
Bauchfreiheit (mm, no load) |
≥200 |
|
Body structure |
|
|
Cab |
Integral sheet metal |
|
Tube doors |
○ |
|
Cargo box（bed） |
Rear side |
|
Battery/motor parameters |
|
|
Battery type |
LFP battery |
|
Battery specification(V/Ah） |
73.6V，240Ah |
|
Battery optional |
– |
|
Lithium electric heating plate |
● |
|
Range (no load) (km) |
≥200 |
|
220V charging plug |
– |
|
110~220V charging plug (wide voltage) |
● |
|
Charging time (20%-100%) (h) |
6~8 |
|
Motor type |
|
|
Rated power (kW) |
10.5KW |
|
Chassis/Wheel Braking |
|
|
Drive form |
RWD/4WD |
|
Front suspension |
Double wishbone coil spring independent suspension |
|
Rear suspension |
Vertical leaf spring (3 pieces) |
|
Drive axle |
Front axle 8.5/15 |
|
Front brake |
Disc |
|
Rear brake |
Drum |
|
Rim |
15X5.5J(steel）● |
|
Tire |
195/65 R15（radial tire）● |
|
power-assisted steering |
● |
|
Brake assist |
● |
|
Inside/outside configuration |
|
|
Door lock |
Electric |
|
Window |
Electric |
|
Front Seat |
Primary/Secondary Independent Seats |
|
Rear seat |
– |
|
Seat headrest |
● |
|
Jump seats |
○ |
|
AC |
○ |
|
Towing |
○ |
|
Front receiver |
○ |
|
Interior rear view mirror |
● |
|
Instrument |
Metric● |
|
Front searchlight |
● |
|
Roof spotlight |
● |
|
AVS Sound Module |
○ |
|
Side retro reflector |
● |
|
Red reflective stickers |
○ |
|
Seat belt |
● |
|
Seat belt certification |
DOT● |
|
Reverse image |
● |
|
Mp5 |
7“MP5● |
|
Fender extensions |
● |
|
Car cover |
○ |
|
Child lock |
– |
|
Front bumper |
larger light holder● |
|
Rear bumper |
● |
|
Pedal rack |
● |
|
Roll cage |
●protective screening |
|
Spare tire |
– |
|
Charger plug |
China standard● |
|
VIN |
●right/○left |
|
Spray wax |
○ |
|
Swatches |
● |
|
Rubber Liner |
○ |
Note In addition to white, red, yellow do not add money, other colors for special colors need to add 300 RMB, charger plug if not the national standard will make up the difference, the difference in 20-100 RMB
“-” indicates that this configuration is not available. “○” represents optional items, which need to be selected and explained; ● Indicates the standard configuration item.
